Belt conveyor Mini Roller

Available in belt widths from 16” to 36”, the Mini Roller includes all the benefits of the Hi Roller in a lower profile design. The bell shaped carrying idler, head, and tail pulleys all have a smaller diameter. This conveyor is well suited for low capacities. The Mini Roller and Lo Roller conveyors provide you with two options for lower profile, lower capacity conveying. The unique spool shaped idler used in the Mini Roller® provides a troughed support for the conveyor belt. The spool shaped idler uses two externally isolated bearings as opposed to six internal bearing as featured on more conventional idlers. Alternatively, the Lo Roller utilizes flat idlers for belt load support and UHMW lined side slides for belt edge support. This design provides a continuous seal along the belt edge for the entire length of the conveyor. The Mini Roller idler is constructed with a heavy wall pipe that passes through the center of the idler. This provides rigid support. The center pipe is then reamed to just the right tolerance to accept the turned and polished stub shaft that passes through the external bearings. The Lo Roller idler is constructed with an integral shaft as opposed to the stub shaft design. This idler can be removed by simply dropping the idler inside the enclosure and raising the belt edge to permit removal through the top of the conveyor. As with all Hi Roller® conveyors, the Mini Roller® is custom designed and built to your specific requirements. Hi Roller® will assist you to determine the best combination of performance and cost to provide you with the safest, most cost effective solution to suit your needs today and in the future.
