Rocker switch 2631LH/2A212000L0

• Terminals: Solder lugs / quick-connect • Electrical Functions: ON - OFF • Number Of Poles: Single pole • Contact Materials: Silver • Frame Type: Plain • Rocker Shapes: Plain • Lamps: Without lamp • Frame Colors: black (standard) Specifications Distinctive Features: • Three rocker shapes : plain, V-shaped or concave • Various rocker colors • Frame with protection guard on 2600LP models • Illuminated or non-illuminated • UL, CSA, VDE and NF (EN 61058-1) approved General Specifications: • Panel thickness : 0.8 mm to 4 mm (.031 to .157) • Operating temperature :- silver contacts (A) : -20 °C to +85 °C (-4 °F to +185 °F)- silver plated contacts (C) : -10 °C to +55 °C (+14 °F to +131 °F) Electrical Specifications: • Max. current/voltage rating with resistive load and approved ratings : see table below. • Initial contact resistance : 10 mΩ max. • Insulation resistance : 1,000 MΩ min. at 500 VDC • Dielectric strength : 2,500 Vrms 50 Hz min. between terminals 3,000 Vrms 50 Hz min. between terminals and metal panel • Electrical life : 10,000 cycles at full load Materials: • Case : melamine/polyester • Frame : polyamide • Actuator : polyamide • Contacts : • A : silver • C : copper, silver plated
