Magnetic flow meter WOLTMAN HRV - W

irrigationfor water

Meters made of corrosion-resistant materials that facilitate measurement over a wide range of flow rates. They are MEÑE and MID certified for use in irrigation and drinking water. ADVANTAGES U0-D0 approved (no straight pipe runs upstream or downstream required). Body in ductile cast iron coated with stove-enamelled food grade epoxy coating. Mechanism fully removable without disassembling the meter from the pipe and made of technical plastics in combination with stainless steel for the metal parts. Optimum hydraulic performance. The meter has the following certificates: – Standard Examination Certificate for irrigation water by the CEM (Spanish Metrology Centre) according to Royal Decree 244/2016, of 3 June, which develops Law 32/2014, of 22 December, on Metrology and Order ITC/279/2008, of 31 January, which regulates the State metrological control of cold water meters, types A and B. -Certificate of Conformity for drinking water Model MID (equivalent to Class B) according to European Directive 2014/32/EU and Royal Decree 889/2006, of 21 July, in compliance with UNE EN 14154, ISO 4064 and OIML R49 standards throughout its range. Pre-equipped for pulse emission. Reed and opto-electronic pulse option. 360º adjustable clockwork with IP 68 protection rating and direct totalisation by means of numbered rollers. Dry, watertight dial with direct magnetic transmission. Mixed reading by means of central hand and numbered drums, very large verification step. Technical specifications WOLTMAN HRV - W Connection diameter: 2″ – 2 1/2″ – 3″ – 4″ – 5″ – 6″ – 8″ – 10″ – 12″ Connection type: Flange
