Box tipper with clamping system

The box tipper is constructed for unloading big boxes with potatoes, grain, vegetables, aso. to the front with very less loss of dumping height. Standard equipment: • Lifting capacity: 2500 kg (with 4 tines 3000 kg) • Tipping angle: 142° to the front • Pallet fork carrier ISO FEM II • With 2 tines ISO FEM II B 1200mm (we recommend 4 tines for models with 2250mm width and more) • Fitting for boxes with 1200-1250mm depth and 1150 to 1250mm height. (Special measures are possible on request) • With hydraulic downholder (tube-form, turnable) • The tipping function needs very less space of 150mm • Measurements: Inner width = Box + 75mm Width over all = Box + 370 mm • With adjustable pressure limiting valve • 2 double acting functions needed
