Engine - Kubota D 1803 diesel 3 cylinders (Hp 49,6 / Kw 37) water cooled STAGE V
Start - electric
Digital display - with speedometer, instruments and service lights
Transmission - hydrostatic with pistons pumps
Hydraulic motors - wheel motors Poclain
Brakes - negative
Controls - 1 lever joystick or 2 lever for speed-and corse control, with servo-control
Frame - with slides and quick connections for accessories
Operator's platform - mechanics
Opening chassis - hydraulically
Driving system - reversible
Driving system - with speed regulator
Guide roller - n. 8 in cast iron with unthreading pins assembled on bearings
Tracks - rubber
Spring tensioner - for the tracks
Heat exchanger - combined water-hydraulic oil
1 hydraulic connection - with piston pump, from 0 to 45 lt/min
12 hydraulic connections - double or simple effect from 18 lt/min
Overall dimensions - mm. 1950x700/900x1450
Weight - Kg. 900
Capacity - Kg. 600
Speed - from 0 to 7 Km/h by gradual change
Treated on all metallic parts - powder painting
Optionals
Operator's platform with opening-closing and inclination hydraulic
Dumper loading platform with double effect cylinder hydraulic tipping
Hoist for Pto
Retractable hoist for Pto
Guide roller with hydraulic tilting
Atomizer
Butt irroration barrow with pump and hose reel
