Flatbed trailer T-149/1 EU

3-axleagricultural14 tons

.Wall height 3×500 mm with thickness 2.5 mm, hot-galvanized .Partitioned side walls .New 385/65- 22.5 wheels .Axles from the renowned ADR company, homologated (EU 2015/68), bar cross-section – square 90, brake size 406×120 412E, 8 M20x1.5 pins .Pallet width .“Y”-type drawbar with exchangeable tip, homologated according to Regulation 55UN ECE and .167/2013*2015/208ND, 40 eye .Hot-galvanized rear bumper, homologated according to Regulations 2015/504 and 167/2013 .Central bolt-locking of walls (bottom sideboards) .Exterior ladder and steps inside cargo box – hot-galvanized – with anti-skid steps facilitating access to cargo box .Two wheel chocks placed in galvanized pockets .Telescopic actuator with articulated suspensions, five-level with 1980 mm pitch. Useful force at fifth level with diameter 140 mm, at nominal pressure 20MPa = 307.9kN (31.4T) .Tipping installation protected against excessive box inclination by cut-off valve .Maintenance support of cargo box, hot-galvanized .12V lighting, homologated, rear bulb lamps, LED perimeter lighting, rear socket for connection to second trailer .Lighting installation connector cable with 7PIN 12V plug .Homologated, double-circuit, pneumatic brake system with automatic braking force adjustment from HALDEX, with output for second trailer. .Parking handbrake with crank .Cargo box frame painted in two steps (immersion in prime coat – protection of construction on profile interiors and exteriors / sprayed top coat) with high-grade PPG paints .Main stringers of cargo box frame made of closed profiles with variable cross-section, made from 6mm sheet. Profile cross-section at highest point 110×300 mm
