Crawler tractor 5K SERIES
mechanical transmission4-cylindercompact

crawler tractor
crawler tractor
crawler tractor
crawler tractor
crawler tractor
crawler tractor
crawler tractor
crawler tractor
crawler tractor
Add to favorites
Compare this product


Characteristics

Type
crawler
Transmission
mechanical transmission
Number of cylinders
4-cylinder
Other characteristic
compact, with cab, 3-point hitch, front PTO, with front-loader, tracked
Engine power

110 ch, 116 ch
(110 hp, 116 hp)

Displacement

3,849 cm³
(130 US fl oz)

Wheelbase

1,850 cm
(728.3 in)

PTO speed

540 rpm, 1,000 rpm
(3,392.9 rad.min-1, 6,283.2 rad.min-1)

Torque

472 Nm
(348 ft.lb)

Maximum speed

Max.: 11.8 km/h
(7.3 mph)

Min.: 0.4 km/h
(0.2 mph)

Fuel tank capacity

130 l
(34.3 gal)

Total length

3,550 mm
(139.8 in)

Total height

2,390 mm
(94.1 in)

Weight

6,425 kg
(14,164.7 lb)

Description

The crawler built to excel on any terrain. The DEUTZ-FAHR 5115K is a state-of-the-art open field crawler tractor that is perfectly at home working on any terrain. Its potent engine, with an impressive 116 HP of maximum power, excellent weight distribution and generously sized tracks translates to a draft capacity comparable to that of a wheeled machine almost twice as powerful. This machine is designed and built for simplicity of use and for extraordinary comfort and reliability, while an undercarriage with 6 track rollers ensures that the weight of the tractor is spread uniformly over the contact area of the heavy-duty track chains. Boasting innovative styling and class-beating performance, and both comfortable and easy to use, the new DEUTZ-FAHR 5115K crawlers are ready to tackle any terrain, and any job from working in the open field to specialised tasks. The low centre of gravity lets you work safely even on particularly steep gradients.

Catalogs

5115K
5115K
2 Pages
SERIES 5K
SERIES 5K
4 Pages
