Impeller pump VISCOPOWER F 570

verticalmobilestationary

The FLUX progressive cavity pump VISCOPOWER F 570 - Industry with planetary gear is suitable to pump thin to medium viscous media. The positive displacement pump works smoothly at a constant pressure and ensures a gentle, pulsation-free pumping. The progressive cavity pumps VISCOPOWER can be used mobile and stationary, has only a few components and can be easily, fast and without special tool dismantled. Technical data: -Viscosity: min. 1 mPas - max. 80.000 mPas1 -Outer tube diameter: min. 53 mm - max. 53 mm -Immersion length: 700, 1000, 1200, 1500 -Materials outer tube: Stainless steel -Seal: Open mechanical seal or closed mechanical seal -Container: 200 l drums, 1000 l IBC, Small containers, Hobbocks, Tanks > 1000 liters Product attributes -Positive displacement pump -Gear ratio two-stage 1:16 or single stage 1:7 -Smooth pumping and with very little turbulences -Low pulsation in relation to the flow -Comprehensive modular system -With open/closed mechanical seal -Also available with variable speed adjustment (transfer proportional to speed) -Pump/shaft/rotor can be dismantled -100% Made in Germany Benefits -Wide range of viscosity can be covered -Optimal for viscous self-flowing media -Also suitable for shear-sensitive media -Transfer at constant pressure -Can be adjusted individually on the media's characteristics -Flow rate adjustable -Flow rate easy to calculate -Intuitive and quick to disassemble and clean -Efficient use of medium -High efficiency -Available with Ex-certification
