Impeller pump VISCOPOWER TR

mobilehorizontalstationary

The FLUX progressive cavity pump VISCOPOWER TR - Industry in horizontal version is perfect for containers that are not accessible from the top. It is used to pump thin to highly viscous, pasty, still flowing media. The positive displacement pump works with little turbulences, at constant pressure and ensures a smooth, pulsation-free pumping. The pump can be mounted on a trolley or a console and can be used mobile or sationary, has only a few components and can be easily dismantled. Technical data: -Viscosity: min. 1 mPas - max. 100.000 mPas -Outer tube diameter: min. 53 mm - max. 53 mm -Length: 400 -Materials outer tube: Stainless steel -Seal: Closed mechanical seal or open mechanical seal -Container: Container with floor drain Product attributes -For containers which are not accessible from above -Positive displacement pump -Smooth pumping and with very little turbulences -Low pulsation in relation to the flow -Comprehensive modular system -Also available with variable speed adjustment (transfer proportional to speed) -Pump/shaft/rotor can be dismantled -Bearing flange between motor and shaft -Drive by three-phase motor, gear motor or FPM compressed-air motors -With open/closed mechanical seal -Shaft in stainless steel -Rotor in stainless steel -The pump is installed dry, i.e. it is not in the medium. -Different stator materials are available: NBR white, FKM, PTFE -100% Made in Germany Benefits -Optimal for viscous self-flowing media -Also suitable for shear-sensitive media -Transfer at constant pressure -Can be adjusted individually on the media's characteristics
