Wastewater pump F 620 S-30 TR

for AdBluesubmersiblecentrifugal

For pumping and conveying of large quantities of heavy flammable liquids out of containers, tanks, open containers etc. The pump is used either horizontally mounted onto a base plate or fixed vertically. Technical data: -Delivery head: max. 12 mwc1 -Viscosity: min. 1 mPas - max. 2500 mPas1 -Diameter pump housing: max. 30 mm2 -Diameter mounting flanges: max. 185 mm2 -Materials outer tube: Stainless steel -Media / Fluids: Acids, AdBlue®, Alkalis, Fuels -Seal: mechanical seal -Container: Tanks > 1000 liters Product attributes -For pumping large quantities of heavy flammable liquids -With console for dry installation -With threaded connection on inlet and discharge side -Consisting of an inner and outer tube as well as a drive shaft mounted in the inner tube -Shaft seal with mechanical sealsin ceramic oxide, O-rings made of FKM -Depending on the model, available with threaded or flanged connections at suction and discharge side Benefits -Can be used horizontally or vertically -Pumps also fluids containing solids -Motor can be changed -Pump is hermetically sealed
