Magnetic flow meter FMJ 100

irrigationfor water

The FLUX flow meter FMJ 100, built according to the nutating disc principle, can be used with FLUX drum pumps e.g. with the evaluation unit FLUXTRONIC® the filled quantity can be displayed. This way filling and dosing processes of almost all kinds of fluids can be performed with maximum precision and highest safety. Technical data: -Flow rate: min. 10 l/min - max. 100 l/min -Filling accuracy: +/- 1 % -Operating pressure: max. 4 bar -Size of solids: max. 1,5 mm -Viscosity: min. 1 mPas - max. 2500 mPas -Housing Materials: Polypropylene -Media / Fluids: Acids, Alkalis Product attributes -Nutating disc meter -Inductive counter - independent of the conductance of the medium -Insensitive to small solids -Easy handling -Easy assembly on pump -No metals in the medium area -Low weight -No mains connections required Benefits -Insensitive to small solids -Easy handling -Easy assembly on pump -Also for non-lubricating media
