Towed sprayer KTR14/1000-140
for viticulturehydraulicfolding arms

Towed sprayer - KTR14/1000-140 - Hans Wanner GmbH Maschinen- und Fahrzeugbau - for viticulture / hydraulic / folding arms

Towed sprayer - KTR14/1000-140 - Hans Wanner GmbH Maschinen- und Fahrzeugbau - for viticulture / hydraulic / folding arms - image - 2

Towed sprayer - KTR14/1000-140 - Hans Wanner GmbH Maschinen- und Fahrzeugbau - for viticulture / hydraulic / folding arms - image - 3

Towed sprayer - KTR14/1000-140 - Hans Wanner GmbH Maschinen- und Fahrzeugbau - for viticulture / hydraulic / folding arms - image - 4

Towed sprayer - KTR14/1000-140 - Hans Wanner GmbH Maschinen- und Fahrzeugbau - for viticulture / hydraulic / folding arms - image - 5

Add to favorites

Compare this product

Characteristics

Mobility

towed

Application

for viticulture

Technology

hydraulic

Other characteristics

folding arms, with diaphragm pump, pneumatic, with piston pump, electric

Capacity

1,000 l
(264.2 gal)

Working width

Min.: 18 m
(59'00" )

Max.: 24 m
(78'08" )

Pump capacity

140 l/min
(37 us gal/min)

Pump pressure

50 bar
(725.2 psi)

Description

with Tangential-blower, reflektorconstruktion and GRP-tank Frame Stable hot galvanised frame construction, support wheel, running axle with adjustable track, lower link attachment, lights, wide-angle PTO shaft on one side Tank GRP tank with integrated water tank, can be switched to system cleaning. By agitator shut off the system cleaning is also possible with full or partially filled tank without changing the concentration.Two tank openings with lids, flushing mechanism in the tank screen, level gauge and filling level indication hose , hand washing tank with drain cock Pump Piston-membrane pump IDS 1401 - 140 l/min at 50 bar Filter Suction filter with automatic shut-off valve, central pressure filter with quick cleaning Control unit N/A Blower Drive Hydraulic stepless drive Blower Tangential-blower Nozzles Single nozzle with drip stop can be swiveled and suppressible, nozzle inserts: Albuz ATR according to choice
