Brass nozzle MOMOJet® series

flat spray

Self-cleaning flat spray nozzle Pipe conn. size: R 1/2" Spray angle: 80° Mean droplet diameter: 300 - 490 μm Strainer: Not included Standard pressure: 0.3 MPa (ca. 3 bar) Spray capacity: 2.00 - 6.00 L/min Air consumption: - Free passage diameter: 0.8 - 1.5 mm The MOMOJet® series nozzles’ features: .Flat spray pattern with a mountain-shaped spray distribution having gradually tapered edges. .If clogged, by reducing the pressure to 0.03 MPa, the nozzle tip is retracted and purges foreign particles. By increasing the pressure to 0.2 MPa and greater, normal spraying is restored. .Straight-through orifice is suitable for multiple nozzle arrangement. APPLICATIONS The MOMOJet® series nozzles have multiple applications: .Cleaning: Wire, felt parts and rollers of paper making machines, steel plates, PCB .Cooling: Steel plates .Foam breaking: Waste water treatment .Others: Applications where recirculated water is being used
