Dump trailer GM 100 SEsemi-mountedsingle-axletandem axle
Add to favorites
Compare this product
Characteristics
- Construction
- dump
- Type
- semi-mounted
- Number of axles
- tandem axle, single-axle
- Application
- agricultural
- Payload
- 10 t ... 20 t
- Brake system
- with hydraulic braking
- Other characteristic
- monocoque
- Empty weight
Max.: 7,920 kg
(17,460.6 lb)Min.: 3,860 kg
(8,509.8 lb)- Loading case lenght
Max.: 7.6 m
(24'11" )Min.: 4.6 m
(15'01" )- Loading case width
2.2 m
(7'02" )
Description
A single tool for transporting and supplying the field: semi-lift dumpers BR 11-16 to 18-27 SE from 11 to 18 T, hydraulic door and stand, lifting from 0.75 to 1.15 m by 2 dual acting cylinders, semi-cylindrical body 1080 mm (1580 double strip as an option), homologation at 25 or 40 km/h, possibility of using extensions (300, 600 or 900 mm).
BR 18-27 SE : lifted
BR 18-27 SE with tarpaulin winder set
Lifting cylinder
Safety valve
Level maintenance safety device
Hydraulic stand
Safety stand on BR 18-27
Hydraulic bracket
Rear door 2 outlets (chute and hatch)
