Screen irrigation filter EKO

cartridgePVCstainless steel

Hydraulic filter with a programmer that cannot be modified by the end user. The programmer can be used with batteries or with a transformer. It is very easy to handle, with a compact design that responds to the needs of the market. Very little water is used in the process to clean the screen cartridge. In its smallest versions (filters of 3″, 4″) Eko filters are ideal for low flow rates. From 3” to 10” Available screens for automatic filters: Standard screen for automatic filters: 0,190 mm Construction materials Body: carbon steel or stainless steel. Joints: synthetic rubber nitrile 60º Shore. Screws: zinc-plated weather resistant. Screen: PVC cartridge and stainless steel heat-welded screen. Suction mechanism: PVC Hydraulic filter, principe “action-reaction”. Programmer that cannot be modified by the end user. From 3” to 10”. SYSTEM / FEATURES The filtration occurs by the physical retention of particles larger than the stainless steel heat-welded screen. It also has great filtration surface and reduced head loss. CONSTRUCTION MATERIALS Body: carbon steel. Joints: synthetic rubber nitrile 60º Shore. Screws: zinc-plated weather resistant. Screen: PVC cartridge and stainless steel heat-welded screen. Suction mechanism: PVC STEEL SURFACE TREATMENT The steel elements are treated internally and externally and an impregnation of NANOTECHNOLOGY. After that, the elements are painted by electrostatic spraying powder paint, epoxy polyester.
