Electric forklift truck MI 50 LD ST5

The MI 50 LD forklift is designed to be used outdoors without constraints. With its simple and robust design, it is perfectly adapted to the handling of bulky and/or long loads. The choice of attachments and its 55 kW Deutz engine give it power and versatility in all situations. Its 600 mm center of gravity and twin front wheels optimize your load capacity and productivity! Technical characteristics Power source Diesel Operator type Seated Load center of gravity 600 mm Load distance, centre of drive axle to fork 598 mm Wheelbase 2300 mm Standard mast reference of the machine FVD 30 Weight Service weight 8810 kg Weight on front axle (laden) / rear axle (laden) 12250 kg / 1560 kg Wheels Tires type Super Elastic Dimensions of front wheels 8.25-15 14PR Dimensions of rear wheels 8.25-15 14PR Number of front wheels / rear wheels 4 / 2 Number of drive wheels 2 Front wheel gauge 1489 mm Rear wheel gauge 1700 mm Dimensions Height of overhead guard (cabin) 2430 mm Seat height/stand height 1350 mm Height of towing bar (coupling height) 710 mm Overall length 4719 mm Length to face of forks 3499 mm Overall width 1990 mm Overall width - Twinned wheels 1990 mm Forks section / width / length 60 mm x 150 mm x 1220 mm Fork carriage ISO 2328 (class/form) A/B 4A Fork carriage width 1700 mm Ground clearance below mast 190 mm Ground clearance at centre of wheelbase 270 mm Aisle width for 800 x 1200 pallet lengthways 5230 mm Internal turning radius (over tyres) 110 mm
