Flatbed trailer T020

mounted3-axlefor bales

The largest of the Metal-Fach bale trailers. The maximum load capacity is 18 tonnes, which is 36 bales in 2 rows. The rear frame can be extended by 4 positions in 150 mm steps to increase the load capacity. The platform has two movable side walls made of pipe sections that can be set up in 4 different configurations. The trailer loading floor has profiled side rims. The loading floor panels is made of durable riffled sheets. The trailer features a rear rotary hitch, and a tail electrical system plug and brake port cluster. The ride and operation are superb thanks to the parabolic spring suspension system. The T020 platform is a 3-axle trailer with a turntable. It comes complete with a JOST tow bar with a 40 mm hitch ring. The trailer has all the required systems for safe transport, loading and unloading. It comes with a hand-operated parking brake based on a crank, a pneumatic dual-line braking system, 2 wheel chocks, stowed in zinc-plated holders, and two ratchets for cargo straps/ropes. Note the other feature-rich accessories: the toolbox, the water tank, the mudguards, and the plastic wheel wings.
