Tipping trailer TB 10 000
tandem axleagricultural10 ton

Tipping trailer - TB 10 000 - METALTECH - tandem axle / agricultural / 10 ton
Tipping trailer - TB 10 000 - METALTECH - tandem axle / agricultural / 10 ton
Tipping trailer - TB 10 000 - METALTECH - tandem axle / agricultural / 10 ton - image - 2
Tipping trailer - TB 10 000 - METALTECH - tandem axle / agricultural / 10 ton - image - 3
Tipping trailer - TB 10 000 - METALTECH - tandem axle / agricultural / 10 ton - image - 4
Tipping trailer - TB 10 000 - METALTECH - tandem axle / agricultural / 10 ton - image - 5
Tipping trailer - TB 10 000 - METALTECH - tandem axle / agricultural / 10 ton - image - 6
Add to favorites
Compare this product


Characteristics

Construction
tipping
Number of axles
tandem axle
Application
agricultural
Payload
10 ton
Other characteristic
3-way
Empty weight

10,000 kg, 12,000 kg, 14,000 kg, 22,000 kg
(22,046.2 lb, 26,455.5 lb, 30,864.7 lb, 48,501.7 lb)

Load volume

Max.: 20 m³
(706.293 ft³)

Min.: 13 m³
(459.091 ft³)

Loading case lenght

4,500 mm, 5,000 mm, 7,450 mm
(177.2 in, 196.9 in, 293.3 in)

Loading case width

2,420 mm
(95.3 in)

Description

TB-type trailers are intended mostly for transport of agricultural produce, in particular loose products such as rapeseed, grain, maize. VERSATILE DESIGN Three-side tipping With a load-carrying body that can be tipped to three sides, TB range of trailers is very versatile. Manoeuvrability of such a combination enables precise unloading on limited space. Refined design The drawbar has rubber shock absorbers. The height of the drawbar eye can be adjusted to match the size of tires used. Extensive standard equipment Even a standard TB trailer is fitted with full LED lights. As a standard, TB trailers are equipped with two wheel chocks which, combined with the parking brake, make parking of the trailer fully safe. As a standard, the trailer is fitted with two-hose braking system connected to the tractor using convenient coil hoses. Upon request, the brake system can be replaced with a single circuit system.
