Mechanical deleafer E3050

flexible finger2-rowlightweight

Mechanical suckering machine, simple and ingenious in its design This suckering machine is robust, lightweight and easy to maintain. This is a mechanical solution to the growing restrictions imposed by environmental standards with regard to chemical suckering. Available in two versions: one that can be coupled to the MULTIVITI chassis and the other to the new COMBIVITI chassis. Two flexible strip rotors High-quality, trunk-friendly suckering through two rotating modules. Each of these modules is equipped with 18 flexible, abrasive strips. The number of strips can be easily adjusted A telescopic system makes it possible to adjust the suckering height from 30 to 50 cm Working speed varies between 1.5 and 3 km/h Suckering as close as possible to the vines The two modules are staggered, one behind the other, to work more efficiently around the vines. The first module cleans the front of the vine through 180° and the second cleans the back of the vine through 180° Row tracking is ensured by two vine-guides above the modules Jig discs at the top and bottom of each module keep the strips at a safe distance from the vines and prevent them from rolling up Mechanical ground tracking The suckering machine is equipped with mechanical ground tracking with a system of parallelograms and springs The two suckering modules independently follow irregularities in ground height The lower discs are in contact with the ground
