Lifting Torque net:62 kNm
Lifting Torque gross:82 kNm
Lifting Capacity at 4 m with Grab:1460 kg
Weight:1530 kg *
Slew Torque:22 kNm
Slewing Angle:370 °
System Pressure:230 bar
Oil Quantity in Tank:100 l
Slew Cylinders:4
Telescopic Stages:1
Support Legs (A or "flap down") by choice:"flap down"
Crane Rotating Gear in Oil Bath:Standard
Self Sufficient Hydraulic System with Pump:Standard
3 Point Linkage:Optional
Control with Mechanical Joysticks:Optional
Cross Lever Control with el. ON/OFF Functions:/
Prop.-hydraulic (low pressure) Joystick control:Standard
Control with Proportional Electrical Joysticks:Optional
High Seat Control:Optional
Radio Remote Control:Optional **
Control Lever Protection:Standard
Double Cast-Iron Pump (tandem) with Double Circuit Control:Optional ***
Piston Pump:/
Single Flow Piston Pump with Multiplier:Optional
Double Flow Piston Pump with Double Circuit Control:Optional
LS Tractor System without its Own Hydraulic System:Optional
Oil Cooler:Standard
