Splitting Force:18 t
Cut Log Diameter:10-42 cm
Tehnical features
Cut Log Length:20-50 cm
Cut Log Diameter:10-42 cm
Sawbar:Husqvarna
Chain:Husqvarna C85
Splitting system "2 Speed Automatic":Standard
Control:Joystick
Oil Quantity in Tank:100 l
Necessary Tractor Capacity:37 kW / 50 HP
Discharge Conveyor - swinging (5 m):S (hydraulic swinging)
Discharge Speed - with Continous Speed Control:0-1 m/s
Weight with Discharge Conveyor:1570 kg
W × L × H - working position:1420 × 7600 × 3900 mm
W × L × H - transport position:1420 × 2450 × 2830 mm
PTO Drive Shaft Walterscheid W2300 SD 15 (L = 710 mm):Standard
Wide angle PTO Drive Shaft Walterscheid WWZ 2480:Optional
Operating Hours Counter:Standard
Splitting Wedge 4-Way:Standard
Splitting Wedge 6; 8; 12-Way:Optional
Sawdust Extractor Fan (integrated, hydraulic or electric):Optional
Separator:Optional
3S-System (Variable Stroke of the Splitting Cylinder):Optional
Power Drive:Optional
Harvester Sawbar and Chain:Optional
