Electric wood splitter CV 22 EK pro

verticaltractor-mountedPTO-driven

Splitting Force:21 t Recommended Tractor Power:27 kW / 37 HP Standard equipment "2 Speed Automatic" valve with two automatic splitting speed levels, depending on operating load on the wedge/ Cast-iron pump, Integrated double-bottom tank containing a large volume of oil Tehnical features Drive Power:6,6 kW / 9 HP Splitting Force:21 t Piston Hub:970 mm Splitting Height:550/1100 mm Splitting Speed (S2- S1)-R*(s/1000mm):(5,6-11,1)-5,6 / (3,6-7,2)-3,6 Oil Flow:30 (1400) / 73 (540) min-1 Oil Quantity in Tank:40 l Recommended Tractor Power:27 kW / 37 HP Dimensions W×L×H×(Ht)**:805×1260×2850×(1850) mm Weight:499 kg Table with extension and lifting device plate:Optional Cast-Iron Pump:Standard Winch (750kg):Optional
