.High Output LED Headlights
.500 Lb. of Total Rack Capacity
.1,830 Lb. Towing Capacity
.Exclusive ProSteer Technology
.27" Duro Tires & 14" Aluminum Wheels
.3,500 Lb. Polaris HD Winch with Synthetic Rope
.56.7" Wide Stance & 11.4"/14"Front/Rear Suspension Travel
.12" Ground Clearnance
ENGINE & DRIVETRAIN
ENGINE TYPE
ProStar® 952cc, 4-Stroke SOHC Twin-Cylinder
FUEL SYSTEM
Electronic Fuel Injection
TRANSMISSION / FINAL DRIVE
Automatic PVT P / R / N / L / H; Shaft Drive
DRIVE SYSTEM TYPE
High-Performance Close Ratio On-Demand True AWD / 2WD
ENGINE BRAKING SYSTEM
Yes
COOLING
Liquid
SUSPENSION / BRAKES / WHEELS
FRONT SUSPENSION
High-Clearance Arched Dual A-Arm 29 cm (11.4") Travel
REAR SUSPENSION
High-Clearance Arched Dual A-Arm 35.5 cm (14") Travel
FRONT / REAR BRAKES
Hydraulic operated disc brakes on front and rear wheels
PARKING BRAKE
Lockable Hand Lever
FRONT TYRES
27 x 9-14; Duro Power Grip II
REAR TYRES
27 x 11-14; Duro Power Grip II
WHEELS
14" Cast Aluminium
DIMENSIONS
BED BOX DIMENSIONS (L X W X H)
N/A
FRONT / REAR RACK OR BOX CAPACITY
91 kg (200 lb) / 136 kg (300 lb)
FUEL CAPACITY
19.9 L (5.25 gal)
GROUND CLEARANCE
30.5 cm (12")
OVERALL VEHICLE SIZE (L X W X H)
234.9 x 144.2 x 143.5 cm (92 x 56.7 x 56.3")
PAYLOAD CAPACITY
235 kg (518 lb)
WHEELBASE
145.8 cm (57")
DRY WEIGHT
450 kg (992 lb)
FEATURES
SEAT HEIGHT
N.C.
CARGO SYSTEM
Lock & Ride®
ELECTRONIC POWER STEERING (EPS)
Standard
HITCH TOWING RATING
830 kg (1,874 lb)
HITCH/TYPE
Standard 5.08 cm (2'') receiver
