Flatbed trailer TR100

self-propelledtandem axleagricultural

The Rayco TR100L trailer is specifically designed to haul the Rayco RG165T-R self-propelled stump cutter. The TR100L features a single-pin lock to secure the stump cutter to the trailer. Standard features include electrostatic powder-coat paint, skid-resistant deck and ramps, electric brakes and tandem Dexter E-Z Lube leaf spring suspension axles. SPECIFICATIONS HEIGHT - 32" Top of Fender, 35" Bottom of Fender, 81.2 cm, 88.9 cm GVWR - 7,000 lb, 3,175 kg WHEELS - 700-15, Max Capacity 2,156 bl @ 60 psi Per Tire (Load Range D), Highway Speed Approved, 977.94 kg @ 413 kPa AXLES - Tandem Dexter E-Z Lube 3,500 lb Rating Each, 1,587.5 kg LIGHTING - Right and Left Tail Lights, License Plate Lighting, Side Marker Lights, DOT Approved BRAKE SYSTEM - 10" x 2.25" Electrical with Trailer Mounted Breakaway Safety Switch and Integral Battery and Charger (Note: Both Axels have Brakes), 25.4 cm x 5.7 cm HITCH - 2" Ball coupler with Safety Chains and Hooks, 5.1 cm OPTIONAL HITCH - 3" I.D. Pintle Hitch, 2 5/16" Ball Coupler, 7.62 cm, 56.67 cm JACK STAND - 2,000 lb Hand Crank (Optional Wheel Available), 907 kg
