Vertical mixing wagon MASTERMIX 2P

towedside discharge2-auger

Standard on all MASTERMIX models, the counter knives ensure better cutting of long forage. Their position in the tank and their shape have been studied to offer the greatest efficiency and better ergonomics. Frame integrated in the tank Rigidity and solidity thanks to the 15 mm steel frame welded directly to the tank, ensuring perfect resistance over time. Economic screw Designed to cut and mix with a minimum of driving force, the MASTERMIX screw is an evolution in itself. Pesée de haute précision sur 3 points Perform accurate mixing controlled by 3 ∅ 70 mm load cells with control screen. Oil bath gearbox Gearbox completely immersed in an oil bath with reservoir and easily accessible control gauge avoiding any regular maintenance at the lubrication level. Standard equipment • MASTERMIX 2-15 and 17 ø 2100 mm • MASTERMIX 2-19 to 25 ø 2400 mm • 6 mm/ 8 mm and 15 mm tanks in s 355 • Frame integrated in the tank • 2 manual counter-knives • PG 1202 screw reducer (11600 Nm torque) - MASTERMIX 2-15 and 17 • PG 1602 worm gearbox (15700 Nm torque) - MASTERMIX 2-19 to 25 Without gearbox • Screw speed at 540 rpm: MASTERMIX 2- 15 and 17: 27 rpm / MASTERMIX 2 -19 to 25: 25 rpm • Distribution through a front right side door with fixed shelf • 3-point weighing with load cells ø 70 • Non-programmable weighing • Direct tractor connection of hydraulic functions (1 x double acting) Control scale • Height adjustable drawbar • Manual kickstand • Frein manuel et hydraulique • Axle # 80 with wheels 400 / 60 15.5 new tires MASTERMIX 2-15 and 17 • Axle # 90 with wheels of 445 / 45 19.5 new tires MASTERMIX 2-19 to 25
