Landscaping rotary cutter XH-1000rear-mountPTO-drivenchain
Add to favorites
Compare this product
Characteristics
- Applications
- for landscaping
- Mounting
- rear-mount
- Other characteristics
- PTO-driven, chain
- Working width
3.2 m
(10'05" )- Tractor power
Min.: 70 ch
(70 hp)Max.: 90 ch
(90 hp)
Description
The XH-1000 has all of the features of the XH-1500 but in a 10′ width
SPECS
Overall width - 139" (3.53m)
Overall length - 198" (5.03m)
Overall length with walking axles - 207" (5.26m)
Transport width, min - 89” (2.26m)
Transport height - 84” (2.13m)
Side band skirt depth - 15 3/8” (.39m)
Side band skirt thickness - 1/4” (6.35mm)
Weight with walking axles, approx. - 7360lbs (3338kg)
Transport hitch weight, approx. - 2100lbs (953kg)
Cutting height - 1.5 to 19.25" (38 to 490mm)
Ground clearance, transport - 18.5" (470mm) (27” tires)
Cutting capacity - 5" material (127mm) with brush blade
Blade overlap - 6.5" (165mm)
Divider gearbox rating - 275 HP (205kW)
Centre/wing gearbox rating - 240 HP (179kW)*
