Landscaping rotary cutter FX-318

for row cropsfront-mountPTO-driven

- Schulte’s first 18 foot flex wing rotary cutter has three sets of rotors - An ultra narrow transport width makes moving this unit extremely safe and simple - Run with the same HP tractor as most 15’ flex wings, but gain the extra 3’ cutting width - Excellent choice for mowing crop residue, pastures, weeds, orchards and roadsides - Single 7 gauge domed deck sheds water and debris and increases life of the rotary cutter deck with this easy clean feature - Available 540rpm or 1000rpm 80° CV drive or 540 equal angle non CV drive - Heavy duty gearboxes & drive system with spun formed 7 gauge stump jumpers ensures durability & perfect balance on the rotary mower SPECS Overall Width - 228” (5.8m) Overall Length - 208” (5.3m) Transport Width - 86” (2.2m)(Singles on wings) 96” (2.4m) (Duals on wings) Transport Height - 109” (2.77m) Deck Thickness - 7GA (3/16", 4.6mm) Weight - 5800 lbs (2631kg) (Depends on configuration) Hitch Weight - 2350 lbs (1066kg)(Depends on configuration) Tractor PTO Speed - 540 or 1000rpm Cutting Height - 1.75" to 16.75" (44.5mm to 425mm) Ground Clearance - 14.75" (42.5mm) Cutting Capacity - 3.5" (89mm) Blade Overlap - 6" (152mm) Divider Gearbox Rating - 260HP (194kw) Center & Wing Gearbox Rating - 225hp (168kw) * Output Shaft - 2.38" (60.3mm)
