Vertical mixing wagon TIGER V1 ME
stationaryfront dischargesingle-auger

Vertical mixing wagon - TIGER V1 ME - SEKO INDUSTRIES - stationary / front discharge / single-auger

Vertical mixing wagon - TIGER V1 ME - SEKO INDUSTRIES - stationary / front discharge / single-auger - image - 2

Add to favorites

Compare this product

Go to the SEKO INDUSTRIES website for more information

Characteristics

Auger orientation: vertical
Mobility: stationary
Discharge type: front discharge
Number of screws: single-auger
Other characteristic: with weighing system, electric motor, hydraulic drive
Capacity in m³: 9 m³, 11 m³, 13 m³
(317.8 ft³, 388.5 ft³, 459.1 ft³)

Description

Tiger V1 ME stationary unifeed mixing wagons vertical TIGER V1 ME/VMS (direct descharge) TIGER V1 ME/VMF (front conveyor) Available in models from da 9 to 13 m³ STANDARD EQUIPMENT -Complete with electric motor -Without electric control board (on request) -N° 1 Chopping-mixing auger fitted with toothed blades -VMS Series = Direct discharge -VMF Series = Rubber front bilateral conveyor 900×2400 mm (WxL) -Epicycloidal gearbox with two speed gear -Independent hydraulic installation with electro valves and push button panel for auxiliaries facilities -N° 2 hydraulically operated counter-blades -Inspection ladder with platform -Sekotronic SK400 weighing system with 15 recipes/15 ingredients -Product containment ring -Axle with steel wheels, hydraulic supporting foot and drawbar for machine movement within the site
