Mounted mulcher FARMLAND 5
flailforestryPTO-driven

Mounted mulcher - FARMLAND 5 - Serrat Broyeurs - flail / forestry / PTO-driven
Mounted mulcher - FARMLAND 5 - Serrat Broyeurs - flail / forestry / PTO-driven
Mounted mulcher - FARMLAND 5 - Serrat Broyeurs - flail / forestry / PTO-driven - image - 2
Mounted mulcher - FARMLAND 5 - Serrat Broyeurs - flail / forestry / PTO-driven - image - 3
Mounted mulcher - FARMLAND 5 - Serrat Broyeurs - flail / forestry / PTO-driven - image - 4
Mounted mulcher - FARMLAND 5 - Serrat Broyeurs - flail / forestry / PTO-driven - image - 5
Mounted mulcher - FARMLAND 5 - Serrat Broyeurs - flail / forestry / PTO-driven - image - 6
Mounted mulcher - FARMLAND 5 - Serrat Broyeurs - flail / forestry / PTO-driven - image - 7
Add to favorites
Compare this product


Characteristics

Type
mounted
Technology
flail
Applications
forestry
Other characteristic
PTO-driven, hydraulic, for tractors
Cutting width

2,000 mm, 2,500 mm, 2,700 mm, 3,000 mm
(78.74 in, 98.43 in, 106.3 in, 118.11 in)

Rotational speed

1,000 rpm
(6,283 rad.min-1)

Tractor power

Min.: 86 ch
(86 hp)

Max.: 500 ch
(500 hp)

Weight

3,091 kg, 3,466 kg, 3,634 kg, 3,980 kg
(6,814.49 lb, 7,641.22 lb, 8,011.6 lb, 8,774.4 lb)

Description

Soil preparation machine up to a depth of 50 cm, for tractors between 250 – 500 HP. Transforms forest land, with stumps and rocks, in land for cultivation avoiding accidents in later processes. Steel-plate chassis, thickness 10 mm. Rotor FIXE TOP of Ø 625 mm. Gearbox with freewheel included. Double synchronous belt transmission. Supports of bearing rotor in steel. Oscillating bearings of double row of rollers. Double ploughshare for opening the land. Front skid shoes. Rear hydraulic hood. Internal reinforcements in chassis. System antiwire in rotor. Compact drive cover. Transmission by cardan to side belts. Model built under EC Normative. Safety indicators visible to personnel.

VIDEO

Catalogs

LEYKAZA
LEYKAZA
1 Pages
