Mounted mulcher OLI 450
hammer16 hammers12 hammers

Mounted mulcher - OLI 450 - Serrat Broyeurs - hammer / 16 hammers / 12 hammers
Mounted mulcher - OLI 450 - Serrat Broyeurs - hammer / 16 hammers / 12 hammers
Mounted mulcher - OLI 450 - Serrat Broyeurs - hammer / 16 hammers / 12 hammers - image - 2
Mounted mulcher - OLI 450 - Serrat Broyeurs - hammer / 16 hammers / 12 hammers - image - 3
Mounted mulcher - OLI 450 - Serrat Broyeurs - hammer / 16 hammers / 12 hammers - image - 4
Mounted mulcher - OLI 450 - Serrat Broyeurs - hammer / 16 hammers / 12 hammers - image - 5
Mounted mulcher - OLI 450 - Serrat Broyeurs - hammer / 16 hammers / 12 hammers - image - 6
Add to favorites
Compare this product


Characteristics

Type
mounted
Technology
hammer
Number of hammers
16 hammers, 12 hammers
Other characteristic
PTO-driven, hydraulic, for tractors
Cutting width

1,600 mm, 1,800 mm, 2,000 mm
(62.99 in, 70.87 in, 78.74 in)

Rotational speed

1,000 rpm
(6,283 rad.min-1)

Tractor power

Max.: 120 ch
(120 hp)

Min.: 60 ch
(60 hp)

Weight

1,059 kg, 1,147 kg, 1,222 kg
(2,334.7 lb, 2,528.7 lb, 2,694.05 lb)

Description

Mulcher with double hydraulic feeder, adapted to cut up residues up to 6-8 cm of diameter in olive trees, citrus fruits, almond trees, walnuts, etc.., with screen replaceble rear gear to set the granulometry, for tractors between 70 and 120 HP. Steel-plate chassis, thickness 10 mm. Rotor POLSER of Ø 450 mm. Gearbox SERRAT. 3 XPC side belt transmission. Forged agricultural hammers Serrat. Hammers guaranteed against breakage. Feeder with system BRALAKC. High torque hydraulic motor reversible. Supports of bearing rotor in steel. Oscillating bearings of double row of rollers. Rear height-adjustable roller. Triple feed chain. GIROSTOP System. Double bearing on rear roller. Reversible toothed rear screen. Model built under EC Normative. Safety indicators visible to personnel.

VIDEO
