Mounted mulcher BIOMASS 150
drumforestryPTO-driven

Mounted mulcher - BIOMASS 150 - Serrat Broyeurs - drum / forestry / PTO-driven
Mounted mulcher - BIOMASS 150 - Serrat Broyeurs - drum / forestry / PTO-driven
Mounted mulcher - BIOMASS 150 - Serrat Broyeurs - drum / forestry / PTO-driven - image - 2
Mounted mulcher - BIOMASS 150 - Serrat Broyeurs - drum / forestry / PTO-driven - image - 3
Mounted mulcher - BIOMASS 150 - Serrat Broyeurs - drum / forestry / PTO-driven - image - 4
Mounted mulcher - BIOMASS 150 - Serrat Broyeurs - drum / forestry / PTO-driven - image - 5
Mounted mulcher - BIOMASS 150 - Serrat Broyeurs - drum / forestry / PTO-driven - image - 6
Add to favorites
Compare this product


Characteristics

Type
mounted
Technology
drum
Applications
forestry
Other characteristic
PTO-driven, hydraulic, for tractors
Cutting width

2,000 mm
(78.74 in)

Rotational speed

1,000 rpm
(6,283 rad.min-1)

Tractor power

Max.: 180 ch
(180 hp)

Min.: 150 ch
(150 hp)

Weight

2,135 kg
(4,706.87 lb)

Description

The SERRAT Biomass recovery mulcher consists in a pick-up rotor which lifts up the pruning of fruit trees, vineyard and branches in a second rotor to mulch it. It can be operated by tractors from 100 to 150 HP and 150 to 170 HP with power take off on the front lift. In the case of a standard tractor with a front power takeoff, it’s possible to hitch a trailer behind to store the mulched material. Mulcher with double reversible hydraulic feeder (system BRALAKC). This mulcher is capable of mulching branches up to 8 – 10 cm of diameter. The size grading is adapted so that the material can be directly used in waste heat boiler of biomasse. 3 point hitch category II-III. Non-wear steel-plate chassis. Double hydraulic feeder, system BRALAKC. 3+4 XPC / XPB side belt transmission. Rotor with system RHENDUEL of Ø 450 mm. Triple feed chain. Reaction and impulse turbine with independant transmission. Front skid shoes. Cardan transmission with mechanical protection. Model built under EC Normative. Safety indicators visible to personnel.
