ENGINE STYE 2stroke air cooling
ENGINE MODEL :1E34FSA
STANDARD POWER(kw/r/min) :0.75W/7500r/min
EFFECTIVE CUTTING LENGTH: 600
REDUCTION RATIO :5.1:1
FORM OF CARBURETORDiaphragm type
MAXED FUEL RETIO 40:1
FUEL TANK CAPACITY(L) 0.65L
METHOD OF STARTING RECOIL STARTING
METHOD OF IGNITION Non-contact ignition
WEIGHT(N.W./G.W.)(kg) 5.6/7.6
PACKING MEASUREMENT(mm) 1110x260x240
Add two-stroke special oil (FC grade)
Use 25:1, fill up the petrol to 1L mark, then add two stroke oil to 25:1 mark. Tighten the lid and shake it several times to mix the two oils together.
180°rotable handle
magneto limit-speed ignition
