Wheat thresher Double Master II

towedPTO-driven

The Double Master II is a versatile machine, capable of collecting peanuts and dry beans. This machine enables you to harvest your beans and peanuts regardless of field or weather conditions, allowing you to give your clients the quality product they deserve. A smart flotation system follows the contours of the soil to ensure a constant recollecting height. This system increases recovery, and reduces intake of dirt and stones. Featuring the exclusive FABI: “Low Impact Active Flow System”, the threshing unit can be adjusted to any crop condition, without jeopardizing the harvesting quality. Specifications Requirements: - Power required: 85hp (65kw) - Trailed tractor hitch - Two hydraulic connections required Recollecting unit: - Intake width: 180cm - Spring type recollecting fingers - 90 recollecting fingers Thresher and separation - Thresher concave diameter: 60cm - Thresher cylinder length: 27cm - PTO shaft rotation: 540 rpm Cleaning system - Cleaning area of the principal screen: 2,36 m² - Adjustable air flow - Turbine diameter: 70cm Storing system: - Storage hopper capacity peanuts (estimate): 1.200kg - Hopper capacity beans: 3.000kg Dimensions - Wheel spacing: 109cm - Wheel size: 467/28 x 8 ply - Empty weight: 3.750kg - Width: 245cm - Length: 660cm - Height: 430cm Optional Tires: 376/30 x 10 ply.
