Wheat thresher Double Master IV

beantowedPTO-driven

The Double Master IV is a versatile machine capable of collecting dry beans. This machine enables you to harvest your beans regardless of field or weather conditions. Featuring the exclusive FABI: “Low Impact Active Flow System”, the threshing unit can be adjusted to any crop condition, without jeopardizing the harvesting quality. Specifications The Double Master IV is a pulled dry bean and peanut harvester - Standard width pick-up, - Big intake roll which moves the straw with the beans directly to the beater - Adjustable cleaning unit with suction fan - Big bunker Specifications Double Master IV: - Power required : 100-130hp - Coupling: Drawing bar TDP - Two hydraulic connections required Pick Up: - Pick up unit : 145/13 - Working width: 185cm - Flexible in rubber recollecting fingers - 90 recollecting fingers Separating and Threshing system - Beater, diameter cylinder: 48cm - Beater cylinder length: 379,6cm - Working speed: 540rpm - Concave screen holes: 2cm Cleaning system - Vibrating sieve cleaning area (m2): 2,98 - Adjustable suction system - Turbine diameter: 700mm Storage system - Bucket elevator : Foldable - 43 pcs of polyethylene - Bucket fastening : 1 central chain - Capacity of the bunker 3000kg Dimensions: - Length: 744cm - Width: 310cm - Wheels: 18.4*26” - Weight: 4640kg
