Dump trailer CORTAL 100

tippingsingle-axleagricultural

The THIEVIN company proposes you, in its range of agricultural trailers CORTAL, the CORTAL 100. This model, which has a GVW of 14 T, is available with a length of body of 4,50 m. The smallest of the CORTAL range This model is equipped with a single 100 mm square axle. Its frame made of 250 x 100 mm tubes, makes the chassis robust. This small model, the smallest of the range of agricultural trailers, will allow you to carry out all your small agricultural works while keeping an interesting transport capacity. Technical characteristics Inside length of the body: 4 500 mm Max. interior body width: 2 320 mm Height inside the box: 1 500 mm Volume with wheat racks: 15,4 m³ Side plates: Steel S355 thickness 4 mm Bottom plate: Steel S235 thickness 4 mm Frame profiles: 250 x 100 x 5 mm Axle: Single square of 100 mm Hydraulic braking: Drum 400 x 80 Original tires: 16R22.5 Arrow: Adjustable mechanical suspension arrow, 9-leaf spring Ring : Fixed ring
