Gasoline engine wood splitter SMH70 D2,6

horizontaltowedmachine

The Branch Logger URBAN SMH70 is powered by a 10 hp Briggs & Stratton VANGUARD engine. The power is transmitted from the engine by the V-belts on an oil-filled gearbox which drives the logger. The logger has road trailer with number plate bracket for easy transport to any place. UP TO DIAMETER 80 MM Part of the machine is: operators manual including declaration of conformity and technical license for trailer. Technical parameters Weight:534 kg Max. diameter of soft freshwood (pine):80 mm Max. diameter of fresh hardwood (oak, hornbeam):65 mm Max. diameter of dry hardwood (oak, hornbeam):50 mm Max. diamensions of block of wood (spruce):60 x 60 mm Max. diameter of wooden board (spruce):190 x 20 mm Log length (not adjustable):6 - 13 cm Logging device inlet dimensions:200 x 200 mm Inlet hopper dimensions:700 x 400 mm Blade rotation speed (rpm):200 / min. Top performance:4 m3/h Engine power:7,5 kW (10 hp) Fuel:Unleaded fuel (95) Fuel tank volume:4 l Average gas consumption:1 - 1,5 l/h Number of logging blades:6 The gap between the blade of the cutting blades:approx. 0,1 mm Lifetime of blades per one grinding:100 - 500 m3 of small logs Chassis:Road with license plate Overrun brake:No Overload protection:Belt slip Dimensions (length x width x height):311x153x340 cm Dimensions in working position (length x width x height):Depends on conveyor position Packaging dimensions (length x width x height):385x153x250 cm Length without towing bar:205 cm Logs output:Conveyor 2,6 m Conveyor drive:V-belt drive Height of the end of conveyor at angle of 30°:206 cm Height of the end of conveyor at angle of 40°:243 cm
