Electric wood splitter EM70 2P

horizontalwheeledmachine

The Branch Logger URBAN EM70 is driven by a three phase 5,5 kW SIEMENS electric motor. The motor´s output is transferred via V-belts to the oil filled gearbox which drives the blade rotors. The logger has 4 wheels for manual handling (2 fixed and 2 swivelling with brakes). UP TO DIAMETER 80 MM Part of the machine is: 50 pcs of raschle bags, operators manual including declaration of conformity. Technical parameters Weight:332 kg Max. diameter of soft freshwood (pine):80 mm Max. diameter of fresh hardwood (oak, hornbeam):65 mm Max. diameter of dry hardwood (oak, hornbeam):50 mm Max. diamensions of block of wood (spruce):60 x 60 mm Max. diameter of wooden board (spruce):190 x 20 mm Log length (not adjustable):6 - 13 cm Logging device inlet dimensions:200 x 200 mm Inlet hopper dimensions:700 x 400 mm Top performance:4 m3/h Engine power:5,5 kW Number of logging blades:6 The gap between the blade of the cutting blades:approx. 0,1 mm Lifetime of blades per one grinding:100 - 500 m3 of small logs Overload protection:Slip + thermal protection Dimensions (length x width x height):205x97x150 cm Logs output:Double bagging Extended description The electric motor The drive is powered by a three-phase electric motor SIEMENS with a power output of 5.5 kW (rated current 11 A, socket 16 A). The motor´s output is transferred via V-belts to the oil filled gearbox which drives the blade rotors. Upon request, a logger can be equipped by hour meter. The Machine handling The logger is equipped for ease of handling by handle on the hopper and by 4 wheels for manual handling. (2 fixed and 2 swivelling with brakes).
