Hydraulic wood splitter HM 70 2P

horizontalmountedmachine

The branch logger URBAN HM70 is driven by a hydraulic motor. It processes material with a diameter of up to 8 cm and the resulting logs length is 6 - 13 cm. The source of hydraulic oil is the hydraulic power unit to which the machine is connected via the connecting frame and 2 hydraulic quick couplings. We produce various types of connecting frames, making it possible to attach a branch logger to a wide range of hydraulic power units such as skid steer loaders, farm manipulators, construction or communal machines. The connecting frame is an accessories. UP TO DIAMETER 80 MM Part of the machine is: 50 pcs of raschle bags, operators manual including declaration of conformity. Technical parameters Weight:420 kg Max. diameter of soft freshwood (pine):80 mm Max. diameter of fresh hardwood (oak, hornbeam):65 mm Max. diameter of dry hardwood (oak, hornbeam):50 mm Max. diamensions of block of wood (spruce):60 x 60 mm Max. diameter of wooden board (spruce):190 x 20 mm Log length (not adjustable):6 - 13 cm Logging device inlet dimensions:200 x 200 mm Inlet hopper dimensions:700 x 400 mm Blade rotation speed (rpm):250 / min. Oil flow rate:40 l / min. Top performance:40 bags per hour Nominal oil pressure:18 MPa Sliding legs:YesNumber of logging blades:6 The gap between the blade of the cutting blades:approx. 0,1 mm Lifetime of blades per one grinding:100 - 500 m3 of small logs Overload protection:Pressure valve Dimensions in working position (length x width x height):102 x 225 x 115 cm Dimensions in transport position (length x width x height):102 x 179 x 123 cm Logs output:Double bagging
