Circular sawmill EA1000

horizontalstationaryelectric

The TITAN Automated Edger uses optical scanning technology to achieve high precision and low waste edging of boards. The entire edging process is automated. First, each board is scanned. The profile of each board is then analyzed by a computer, which decides on the best product to maximize recovery. Decisions are based on both volume recovery and product value. After scanning, the boards pass through an alignment station and then are sawn. The V-AE is capable of handling an average of 20 boards per minute and is the ideal machine to edge boards coming from the TITAN Resaw. Electric servo sizing system achieves any width of cut without complication. Parallel PLC / computer control systems allow the machine to be switched over to manual mode with a single button. Online support allows our technicians to dial into your machine to troubleshoot it remotely. Overall, the TITAN Automated Edger is a simple, robust and automated solution to your edging needs. Features •Optical scanning on the run •Easy to use windows interface •Mechanized material handling for fast, accurate board alignment POWER SELECTIONS Power Selections:22 kW (30 HP) Electric 30 kW (40 HP) Electric CUTTING CAPACITIES Min. Width of Cut:40 mm Production Rate:20 boards/min (average) BLADE Number of Blades:2 Blade Diameter:450 mm (17 1/2") Blade Kerf:5 mm (0.195”) Blade Adjustment Method:Electric Servo Blade position:Two Centered Blades FEED SYSTEM & OPERATION Feed Speed:80 - 140m/min (260 - 450ft/min) Board Alignment:Automated mechanical board alignment Material Hold-down:Powered Pneumatic Hold-down Rollers Scanning:Optical Material Scanner System
