Mechanical forestry winch W-200

tractor mounted

THE CABLE WINCH TO MEET THE MOST EXTREME DEMANDS The W-200 is the biggest and strongest cable winch in our range. It is ideally suitable for very long cableways with very high load capacities. The cable winch is available with different diesel and electrical motors. The cable winch has a hydraulically controlled safety brake in the drum, which closes with a spring action with approx. 15 t braking force. The high-performance air eddy current brake has a braking performance of 400 to 2’000 HP, which is continuously adjustable during operation. The large gearwheel and the external bearing of the vane are lubricated by means of automatic central lubrication with an indicator light. The very big cable drum with a diameter of 966 mm reduces wear when winding long mainlines with large diameters. Like all Wyssen cable winches, the W-200 has a large-dimensioned fine-acting two-shoe brake in the drum, which has a braking area of 1.6m² in all. The W-200 cable winch is predominantly used with the MSK 2 and MSK 3 motorised skyline crane with high load capacities and long runways.
